The 2027 Grand Design Lineage Series VT LVT1 redefines luxury van life, built on the capable Ford Transit chassis with a 3.5L V6 engine. Inside, a 54" x 80" flip-up bed offers comfortable rest, while the industry-first InvisaCook undermount induction cooktop conserves counter space with a sleek Italian porcelain surface. The AquaHaven Rainshower System transforms from living space to full shower, and the Stealth Split AC System delivers whisper-quiet 20K BTU cooling without a bulky rooftop unit. A 400-watt solar system and 30-amp shore connection keep you powered on or off the grid. Every detail is engineered for real adventure van living, without compromise.

NEW 2027 Grand Design Lineage LVT1

GVWR:

9,950 lbs.

GCWR:

12,600 lbs.

Length:

20' 11"

Sleeps:

up to 2

Stock: 27-23258N • Location: Tulsa

KEY FEATURES

1+3+5 Warranty

Camp with confidence, Grand Design is secured by a robust warranty package: 1-year limited, 3-year structural, and 5-year frame coverage.

Ford EcoBoost® Engine

The gas-powered Ford EcoBoost® engine, paired with a 10-speed transmission, ensures superior high-elevation performance and reliable power.

Invisacook Hidden Induction Cooktop

A pioneering, invisible induction technology beneath your counter, transferring energy directly to cookware for a clean, minimalistic, and effective cooking surface.

East/West Flip-Up Bed

The innovative 54" x 80" East/West flip-up bed design provides residential comfort while maximizing valuable living space.

48V Lithionics System

Delivers reliable power for longer adventures away from shore power—up to 3 days with AC using optional second battery.

Sharkbite Plumbing

Engineered for maximum durability and flexibility, this premium piping system offers superior frost resistance and simplifies maintenance, providing long-lasting peace of mind.

360 TOUR

SPECS AND OPTIONS

FACTORY-ADDED OPTIONS

Ford Transit 350 AWD
Exterior Color - Wild Green
Spare Tire Carrier
Standard Power Pkg
SafeRide RV Roadside Assistance
RVIA Seal
Tuned Falcon Adjustable Rear Shocks
Starlink Internet

DOWNLOAD MSRP SHEET

SPECS

Exterior Length: 20' 11"
Exterior Width: 6' 9"
Exterior Height: 10' 2"
Interior Height: 6' 4"
Awning Length: 11' 6"
Fuel Type: Gasoline
Fuel Capacity: 25 gal
Fresh Water Capacity: 34 gal
Gray Water Capacity: 23 gal
GAWR Front: 4,630
GAWR Rear: 6,100
GVWR: 9,950
GCWR: 12,600
Tire Size: 255/70R16 120/117S
Wheel Base: 148"
Bed Size: 54 X 80
Dinette: 36” bench seat, 28” x 18” dinette table, expandable to 44” x 18”
Water Heater: 2.5 gal
Refrigerator: 3.20 cu. ft.
Furnace: 6,800 BTU
AC: 20,000 BTU
Chassis: Ford W2XC T350 (long) HR CARGO AWD
Engine: 3.5L V6 GTDi
Transmission: 10-speed automatic
HP: 310 HP
Torque: 400 ftlb @ 2500 rpm
Sleeping Capacity: 2
Sleeping Areas: 1 to 2
Seat Belt Position: 4
Coach Batteries: 8,448 Watt-Hours 51V Lithionics battery(5,120 Watt-Hours with Pop-Top Option), prepped for 2nd battery with battery tie downs and Y harness connected to external Battery Management System - BMS
Solar: 360 watts solar standard. 300 watt solar with pop-top option. 720 watt solar awning option available
Shore Power: 30 AMP

STANDARD FEATURES AND PACKAGES

EXTERIOR

Van Compass Stage 3 Topo 2.0 Lift (Stage 4 optional)
Luverne driver and passenger running boards
Power rotating front light bar 15,200lm (deleted with pop-top option)
(2) rear pod lights 2,850lm
Polyplastic Double Pane acrylic operable windows
11.5ft Girard Armless Awning with Wind Sensor
Exterior light on underside of running boards and side capsules
Vista Double Pane acrylic panoramic skylight
Custom molded side capsules
Spare Tire Carrier
Quick connect exterior shower
Rear storage deck
Starlink prep included bracket and power cord

CONSTRUCTION

2" Plascore Honeycomb composite floor with bottom radiant barrier
2tec2 Woven Fabric flooring
Alpha insulation and 3M Thinsulate
CNC Routed Wall Panels
Thermoformed ABS dinette and kithentte panels
Welformed Automotive fabric bedroom panels
SharkBite Evo Pex Push2Connect Plumbing System (Max SS braided shut offs)
Soft Touch perforated Ceiling
5,000lbs Tow Hitch w/ 7 way round and 4 way flat plug (removed when selecting Pop-Top option)

FRAME-CHASSIS

Ford Transit Cargo AWD High Roof 148" Wheelbase
GVWR 9,950 lbs. / GCWR 12,600 lbs.
3.5L EcoBoost V6
Transmission: 10-Spd Automatic w/OD & SelectShift
3.73 Limited-Slip Axle Ratio
Ford Connectivity Package (1-Year Included)
Black High-Intensity Discharge (HID) Headlamps
SYNC 4 Includes 12" center display, Bluetooth, dual USB ports,wireless Apple CarPlay and Android Auto compatibility
Dual Alternators (250 Amps Each)
Fixed Rear Cargo Door Glass - Rear-Window Defroster
Keyless Entry Keypad
Adaptive Cruise Control w/Lane Centering. Includes stop and go and predictive speed assist
Side Parking Sensors
Blind Spot Information System w/Cross Traffic Alert
Connected navigation and 360-degree camera
Battery run down protection
SiriusXM with 360L AM/FM/HD/Satellite radio
Cockpit Privacy Shades (Windshield, Driver & Passenger)
Swiveling Driver and Passenger Seat
Ford Co-Pilot360 w/Side Wind Stabilization electronic stability control system with antirollover
Dual AGM Batteries (70 Amp-hr Each)
Heated Driver and Passenger Seats
Front Cup Holders
USB-C Socket
Heavy Duty Trailer Tow Package
Ford Upfitter switches
Custom Recover on Driver and Passenger Seat

UTILITIES

Firefly Integrations® Touch Screen Command Center, Bluetooth® Switches & Smart Phone App (Global)
3,000 Watt Lithionics 51V Inverter
SDG Mini Split 51V AC (20,000 BTU)
Eberspacher/Espar Airtronic gasoline heater
Duoetto Electric water heater
12V Water Pump
12V Heat pads (Fresh and Gray tanks)
Carbon-Monoxide, LP/ Smoke Detectors & Fire Extinguisher
8,448 Watt-Hours 51V Lithionics battery(5,120 Watt-Hours with Pop-Top Option)
Prepped for optional 2nd battery including Y harness for external BMS and mounting brackets
30 Amp Electrical Service
Victron Solar Charge Controller
Nomadic Bi Directional 12v - 51v DC to DC converter
(2) 180 Watt Merlin Solar Panels (300 Watt Apollo panel with Pop-Top option)
Maxx Air Fan

INTERIOR

Easy Assist Handle
Forward Facing Bench Seat with 3point harness and CRS
Vinyl laminated cabinetry
Under Bench pull out drawer
Integrated black out window shades and screens
Multiple charging ports
Pull out hooks
Expandable dinette table with two mounting locations

KITCHEN

Thetford 3.18 Cu Ft 12V Drawer Style Refrigerator
Invisacook Hidden Single Burner Induction Cooktop
Prepped for Air Fryer/Convection Microwave Oven
Porcelain countertop
Stainless Steel 15" x 15" x 6" Sink with Cutting Board Cover
Matte Black pull out Kitchen Faucet
Pop Up Spice Rack
Positive locking latches
Dove Tail Drawer Box
Soft-Close drawer slides

BEDROOM

54” x 80” East/West Flip-Up Bed
Under Bed Storage
LED Reading Lights
USB-C Charging Ports
Phone Holder
Samsung Freestyle Projector
Motorized 50" Projector Screen
Passenger side Bed Base storage doors

BATHROOM

Thetford Cassette toilet with electric flush and 4.7 gal tank
Venting window
Rainfall shower head
Medicine cabinet Mirror with integrated LED lighting
Tambour style roll-away shower doors
30" x 54" enclosed overall size
Built in shower wall storage cubbies

LINEAGE SERIES VT PACKAGE

Ford Transit Trail 350 AWD High Roof 148" WB
Spare Tire Carrier
Standard Power Package: 3000W Inverter, 48V Lithionics Lithium Ion 165AH Battery, 2nd Alternator(Ford), DC to DC Charger
SafeRide RV Roadside Assistance
RVIA Seal
